tomography ［J］ Measurement，2022，202：111852.
［ 9 ］ HOLMES C， DRINKWATER B， WILCOX P. The post-processing of ultrasonic array data using the total focusing
method［J］ . Insight-Non-Destructive Testing and Condition Monitoring，2004，46（11）：677-680.
［ 10］ HOLMES C， DRINKWATER B， WILCOX P. Advanced post-processing for scanned ultrasonic arrays： Applica⁃
tion to defect detection and classification in non-destructive evaluation ［J］ Ultrasonics， 2008， 48（6/7）：
.
636-642.
［ 11］ SHI S Q， LIN L， LUO Z B， et al. Resolution enhancement of ultrasonic imaging at oblique incidence by using
.
WTFM based on FMC-AR［J］ Measurement，2021，183：109798.
［ 12］ GE L，LI Q，WANG Z，et al. High-resolution ultrasonic imaging technology for the damage of concrete structures
based on total focusing method［J］ Computers and Electrical Engineering，2023，105：108526.
.
［ 13］ ZIELIŃSKA M， RUCKA M. Internal imaging of concrete fracture based on elastic waves and ultrasound computed
tomography［J］ Measurement，2022，202：111852.
.
［ 14］ REYAZ S U， BENIWAL S， GANGULI A. Application of plane wave imaging and processing for measurement of
.
reflectors in concrete［J］ IEEE Transactions on Instrumentation and Measurement，2024，73：1-11.
［ 15］ BENIWAL S， GANGULI A. Defect detection around rebars in concrete using focused ultrasound and reverse time
.
migration［J］ Ultrasonics，2015，62：112-125.
［ 16］ GROHMANN M，NIEDERLEITHINGER E，BUSKE S. Geometry determination of a foundation slab using the ultra⁃
sonic echo technique and geophysical migration methods［J］ Journal of Nondestructive Evaluation，2016，35（1）：17.
.
［ 17］ MERABET L， ROBERT S， PRADA C. The multi-mode plane wave imaging in the Fourier domain： Theory and
applications to fast ultrasound imaging of cracks［J］ NDT & E International，2020，110：102171.
.
［ 18］ 常至轩，徐鑫涛，武二永，等 . 基于超声平面波成像的钢轨螺孔裂纹检测方法研究［J］ 仪器仪表学报，
.
2024，45（6）：144-155.
［ 19］ REYAZ S U， BENIWAL S. Geometry measurement of subsurface cracks in concrete from ultrasonic images［J］
.
Measurement，2025，240：115624.
［ 20］ WALARAVEN J C，REINHARDT H W. Theory and experiments on the mechanical behavior of cracks in plain and
.
reinforced concrete subjected to shear loading［J］ Heron，1991，26（1A）：23-33.
［ 21］ 徐磊，姜磊，周昌巧，等 . 基于多重点云与分级聚合的全级配混凝土三维细观结构高效生成方法［J］ 水利学
.
报，2022，53（2）：188-199.

Research on quantitative detection method of internal cracks in concrete based on
ultrasonic plane wave imaging

1 1，2 1 1，2 1，2 1，2，3

SUN Linyuan ，HUANG Hao ，LIU Yang ，ZHEN Li ，ZHANG Xinmiao ，CHEN Gaixin

（1. China Institute of Water Resources and Hydropower Research，Beijing 100038，China；

2. State Key Laboratory of Water Cycle and Water Security，Beijing 100038，China；

3. Key Laboratory of Engineering Materials of Ministry of Water Resources，Beijing 100038，China）

Abstract：This paper proposes an angle-corrected compound plane wave imaging method to address the issues of
strong artifacts and poor accuracy in crack angle detection associated with traditional compound plane wave imaging
methods when detecting internal cracks in concrete. First，finite element simulations of ultrasonic detection of inter⁃

nal cracks in concrete microstructure models were conducted. Subsequently，the detection mechanisms and identifica⁃
tion effects of the traditional compound plane wave imaging method and the proposed angle-corrected method were
compared and analyzed. Quantitative identification criteria for internal crack angles and lengths were provided，and

the validity of the proposed method was demonstrated. Finally，the effects of aggregate size，concrete wave velocity，

and crack depth on the angle-corrected compound plane wave imaging method were analyzed. The results indicate
that the proposed method offers better detection performance. Although an increase in aggregate size can affect the
identification accuracy of the method，the impact is minimal. The method maintains good identification performance

even when the crack depth exceeds 10 cm. This study provides a theoretical basis for the quantitative detection of
internal cracks in concrete in practical engineering applications.

Keywords：internal cracks in concrete；meso-structure；angle correction；plane wave imaging；image recognition
