［ 20］ CAMANHO P P，DAVILA C G，DE MOURA M F . Numerical simulation of mixed-mode progressive delamina⁃
tion in composite materials［J］. Journal of Composite Materials，2003，37（16）：1415-1438 .
［ 21］ 章鹏，潘定才，郑晶星 . 抽水蓄能电站高压水道钢筋混凝土衬砌技术特点［J］. 水力发电，2017，43（11）：
23-26 .
［ 22］ 常晓林，胡超，马刚，等 . 模拟岩体失效全过程的连续-非连续变形体离散元方法及应用［J］. 岩石力学与
工程学报，2011，30（10）：2004-2011 .
［ 23］ ZOU Z，REID S R，LI S，et al . Modelling interlaminar and intralaminar damage in filament-wound pipes under
quasi-static indentation［J］. Journal of Composite Materials，2002，36（4）：477-499 .
［ 24］ 周利 . 水工隧洞钢筋混凝土衬砌内水外渗耦合分析与设计方法研究［D］. 武汉：武汉大学，2020 .
［ 25］ 杨利福，常晓林，周伟，等 . 基于变形离散元法的重力坝地震开裂分析［J］. 振动与冲击，2016，35（7）：
49-55 .
［ 26］ 李宁，刘波 . 城门洞型压力隧洞衬砌限裂配筋设计方法研究［J］. 岩石力学与工程学报，2013，32（12）：
2409-2414 .
［ 27］ 张有天 . 水工隧洞建设的经验和教训（上）［J］. 贵州水力发电，2001，15（4）：76-84 .
［ 28］ 沈威 . 水工隧洞钢筋混凝土衬砌限裂设计试验研究［J］. 水电能源科学，2010，28（5）：78-81 .
［ 29］ 郑治，刘杰，彭成佳 . 水工隧洞受力特性研究和结构设计思路［J］. 水力发电学报，2010，29（2）：190-196 .
［ 30］ 刘建强，张秀芳 . 水工隧洞素混凝土衬砌开裂过程弹性分析［J］. 水电能源科学，2009，27（3）：87-90 .

Hydraulic fracturing analysis method of reinforced concrete lining in hydraulic tunnel

1
1
2
1
ZHOU Li 1，2 ，SU Kai ，WANG Yang ，ZHANG Yanjun ，ZHU Hongze ，WU Hegao 1
（1. State Key Laboratory of Water Resources and Hydropower Engineering Science，Wuhan University，Wuhan 430072，China；
2. Changjiang Institute of Survey，Planning，Design and Research，Wuhan 430010，China）
Abstract： The cohesive element with hydro-mechanical coupling property is introduced to simulate the lin⁃
ing crack and lining-rock interface. In this way， the discontinuous displacement characteristics of lining
crack and interface gap can be taken into consideration，as well as the flow characteristics of pressure wa⁃
ter inside. Combined with the indirect-coupled method of hydro-mechanical interaction， the hydraulic frac⁃
turing algorithm of reinforced concrete lining in hydraulic tunnel is proposed. The development history of lin⁃
ing crack and the evolution of crack width are explored，as well as the water pressure transfer characteris⁃
tics inside lining crack and interface gap. Based on this， the influences of conditional cooperation between
lining and surrounding rock are analyzed systematically. Through the calculation and analysis， it can be
found that the process of crack initiation and propagation is short and inseparable during the water-filling
period of hydraulic tunnel. Subsequently， the water pressure inside lining crack suddenly increases， and
the effect of inner water exosmosis accelerates. After the cracking of lining， the water pressure inside lin⁃
ing crack slightly declines along the radial direction， and the pressure magnitude is relatively close to the
inner water pressure. With the conditional cooperation considered，the water flow channel formed by the lin⁃
ing crack and lining-rock interface can play a role in transmitting water pressure，resulting in a more uni⁃
form distribution of water pressure outside the lining. The lining cracks are in a relatively stable state，and
the distribution of lining cracks is small in number and large in spacing. This is more consistent with the
results of field tests.
Keywords： hydraulic tunnel； reinforced concrete lining； hydraulic fracturing； cohesive element； conditional
cooperation

（责任编辑：王冰伟）
