Page 88 - 2025年第56卷第11期

.
［ 9 ］ 凌永玉，刘立鹏，汪小刚，等 . 大尺寸水工隧洞衬砌物理模型试验系统研制与应用［J］ 水利学报，2020，51
（12）：1495-1501.
［ 10］ 窦金熙，赵卫全，路威，等 . 引水隧洞复杂裂隙围岩高压灌浆浆液扩散过程研究［J］ 中国水利水电科学研究
.
院学报（中英文），2023，21（6）：565-573.
.
［ 11］ 李泽发 . 水工输水隧洞衬砌结构裂缝成因及预防［J］ 河南水利与南水北调，2019，48（6）：50-52.
［ 12］ 田振华，李宝石，王经臣 . 水工隧洞混凝土衬砌裂缝监测与成因分析［J］ 水力发电，2017，43（9）：45-48.
.
［ 13］ 陈晨，曹瑞琅，姚磊华，等 . 考虑主筋约束作用的高压水工隧洞衬砌裂缝开度研究［J］ 水利水电技术，
.
2018，49（11）：75-81.
.
［ 14］ 王玉杰，陈晨，曹瑞琅，等 . 高内水压力隧洞钢筋混凝土衬砌裂缝控制标准［J］ 水力发电学报，2020，39
（9）：111-120.
［ 15］ 张志强，李永珑，王海彦，等 . 钢筋锈蚀劣化对隧道衬砌结构性能的影响［J］ 中国公路学报，2014，27（8）：
.
73-81.
［ 16］ 李明超，张梦溪，王孜越 . 考虑诱导缝的碾压混凝土重力坝控裂结构温度场与温度应力数值分析［J］ 水利学
.
报，2017，48（5）：551-559，567.
［ 17］ 邹 仕 鑫 . 仙 游 抽 水 蓄 能 电 站 2 号 引 水 隧 洞 充 排 水 试 验 实 测 数 据 分 析［J］ 中 国 水 能 及 电 气 化 ， 2014（2）：
.
48-52.
［ 18］ 侯靖 . 天荒坪抽水蓄能电站高压隧洞充水试验实测资料分析［J］ 水利水电科技进展，2009，29（2）：27-31.
.
［ 19］ 苏凯，周鑫，郝军刚，等 . 高压钢筋混凝土岔管设计理论与应用进展［J/OL］ 工程科学与技术，1-15［2025-
.
/
.
03-05］ http：/kns. cnki. net/kcms/detail/51. 1773. TB. 20241122. 1449. 001. html.
［ 20］ 王锦国，周志芳，黄勇 . 基于压水试验资料的岩体透水性分形特征研究［J］ 岩石力学与工程学报，2003（4）：
.
562-565.
Experimental study on physical model of reinforced concrete lined
pressure tunnel with inducing joints
WU Weijiang ，WANG Xiaogang ，LIU Xueshan ，YING Pengtao ，
1
3
1，2
3

4
SHAO Minglei ，ZHANG Qiang 1

（1. State Key Laboratory of Water Cycle and Water Security，China Institute of Water Resources and

Hydropower Research，Beijing 100038，China；2. College of Transportation Science & Engineering，Nanjing Tech University，

Nanjing 211816，China；3. Engineering Construction Management branch of China Southern Power Grid Peak Regulation and

Frequency Modulation Power Generation Co.，LTD，Guangzhou 511499，China；4. China Power Construction

Group Northwest Survey Design and Research Institute Co.，LTD，Xi’an 710065，China）

Abstract：Reinforced concrete lining is a preferred lining structure type for pressure tunnels，which may experience

cracking under high hydraulic heads. However，the location and number of cracks are random，making effective

monitoring and control difficult and introducing uncertainty during the long-term safe operation of the tunnel. To over‐
come the shortcomings of traditional reinforced concrete linings，a new structure of reinforced concrete lining with

inducing joints has been proposed，ransforming passive cracking into active cracking. Through conducting physical
t
model tests on the water filling and emptying of pressure tunnels with the new lining structure，the stress characteris‐

tics of the lining structure during the first and second filling and draining processes have been analyzed，thereby vali‐
dating the effectiveness of the new lining structure. The test results indicate that during the initial water filling pro‐

cess，after the lining cracks，the water pressure on the outside of the lining experiences a rapid increase. As the pres‐

sure difference between inside and outside of the lining gradually decreases and approaches equilibrium，the lining

and the reinforcement transition from a tensile state to a compressive state circumferentially. In the second filling and
emptying process，the water inside and outside of the lining are connected，with water pressure rising and falling syn‐

chronously. The initial circumferential stress of the lining shows a transient tension and then a gradual compression

state. After the first and second water fillings，the reinforced concrete lining with a inducing joint had only one

through-crack along the inducing joint，with no cracks in other areas. The results of the model tests confirmed that the

reinforced concrete lining containing inducing joints can achieve controllable crack locations，measurable crack

widths，and targeted corrosion prevention for the reinforcement，overcoming the shortcomings of traditional rein‐

forced concrete linings and providing new ideas for the design of permeable reinforced concrete linings in high-head
pressure tunnels.

Keywords：pumped storage power stations；pressure tunnel；reinforced concrete lining with inducing joints；physi‐

cal model testing
（责任编辑：韩 昆）
— 1479 —
