Research on ice concentration in Heilong River based on the UAV low-altitude remote
sensing and OTSU algorithm

1，2 1 1，2 1
WANG Enliang ，HU Shengbo ，HAN Hongwei ，LIU Chengqian
（1. School of Water Conservancy and Civil Engineering，Northeast Agricultural University，Harbin 150030，China
2. Heilongjiang Provincial Key Laboratory of Water Resources and Water Conservancy Engineering in Cold Region，Harbin 150030，China）

Abstract： In order to improve the timeliness and accuracy of ice change information acquisition， this pa⁃
per proposed a new method of extracting ice concentration based on unmanned aerial vehicles remote-sens⁃
ing images and OTSU algorithm. In this study， taking the Mohe section of the Heilong River as the re⁃
search object， firstly， drift ice images in ice flood period were captured by the unmanned aerial vehicles
equipped with a high-resolution sensor in top view. The advantages and disadvantages of four image thresh⁃
old-selection methods were compared and analyzed. According to the features of the original ice grayscale
images， meanwhile， the ice and background were separated by combining with top-hat transformation and
OTSU threshold segmentation. In order to avoid the influence of sunlight and waves，the article adopted ar⁃
ea denoising method，and the results showed that the area denoising method was effective and rapid in re⁃
moving reflective point. A graph showing how ice concentration changed with time had been plotted by ex⁃
tracting the ice concentration based on the ice binary image. The results show that the OTSU algorithm ran
fast and had high segmentation accuracy， which is suitable for the field of ice image segmentation. The
maximum ice concentration was 81.05%，and after an ice jam occurred in the upstream，the monitoring re⁃
sults showed that ice concentration dropped rapidly until the ice jam was lifted， the ice concentration re⁃
turned to 60%. The results were in accord with the situation observed on site. The method proposed in this
paper is accurate and effective，which provides a new technical means for monitoring ice change information.
Keywords： unmanned aerial vehicles； OTSU algorithm； ice concentration；threshold segmentation；top-hat
transformation
