［ 10］ 翟亚飞，毕仲辉，唐彧杰，等 . 基于 NGA 模型的主余震序列作用下重力坝损伤破坏研究［J］. 水利学报，
2021，51（2）：152-157 .
［ 11］ 陈厚群，郭胜山 . 混凝土高坝-地基体系的地震损伤分析［J］. 水利学报，2012，43（S1）：2-7 .
［ 12］ 郭胜山 . 基于并行计算的混凝土坝-地基体系地震损伤破坏过程机理和定量评价准则研究［D］. 北京：中国
水利水电科学研究院，2013 .
［ 13］ LUBLINER J，OLIVER J，OLLER S，et al . A plastic-damage model for concrete［J］. International Journal Sol⁃
ids and Structures，1989，25（3）：299-326 .
［ 14］ 中国水利水电科学研究院 . 丰满水电站全面治理（重建）工程混凝土重力坝全级配混凝土动态性能试验研
究报告［R］. 北京：中国水利水电科学研究院，2018 .
［ 15］ 郭 胜 山 ，陈 厚 群 ，李 德 玉 . 重 力 坝 与 坝 基 体 系 地 震 损 伤 破 坏 分 析［J］. 水 利 学 报 ，2013，44（11）：
1352-1358 .
［ 16］ ABAQUS Theory Guide［M］. ABAQUS Inc . USA，2014 .
［ 17］ 闫春丽，涂劲，郭胜山 . 某重力坝考虑混凝土拉压损伤的地震响应分析［J］. 中国水利水电科学研究院学
报，2020，18（2）：112-120 .
［ 18］ 李明超，张佳文，张梦溪，等 . 地震波斜入射下混凝土重力坝的塑性损伤响应分析［J］. 水利学报，2019，
50（11）：1326-1338 .

Damage constitutive model including tension-compression conversion
for dam concrete under dynamic cyclic loading

TU Jin，LI Deyu，GUO Shengshan，LI Chunlei，WANG Haibo
（China Institue of Water Resources and Hydropower Research，Beijing 100048，China）

Abstract： In the seismic safety evaluation of concrete dams， the change of elastic modulus of concrete in
the process of transition from tension state to compression state （tension compression transition） in the dam⁃
age constitutive model of concrete dam under dynamic cyclic load is generally based on the so-called "uni⁃
lateral effect" assumption of commercial software ABAQUS，which considers that the elastic modulus of con⁃
crete immediately returns to the initial elastic modulus. The rationality of the above assumptions is lack of
experimental verification， which directly affects the reliability of seismic safety evaluation of concrete dams.
Through the observation and analysis of the test results of the whole process of tension compression transfor⁃
mation of fully graded dam concrete，it is found that the elastic modulus of concrete does not immediately
return to the initial elastic modulus when it enters the compression state from the tension state，but continu⁃
ously and gradually returns to the initial elastic modulus from the damaged elastic modulus， during which
the original tensile residual strain rapidly decreases to a smaller value under the action of the compressive
stress，It is pointed out that the so-called "unilateral effect" hypothesis of ABAQUS is not in line with the
actual situation. Based on the experimental results of the whole process of tension compression transforma⁃
tion of fully graded dam concrete， this paper proposes the idea of adopting the double broken line model
for the stress-strain relationship during tension compression transformation after the occurrence of tension
damage. According to this， the corresponding analytical expression of stress-strain relationship is derived，
and a numerical constitutive model closer to the real situation of concrete tension compression transforma⁃
tion is constructed. Through the calculation and analysis of the actual project， it is pointed out that the
damage constitutive model of the commonly used compression elastic modulus immediately restored to the
initial elastic modulus overestimates the stiffness of the dam body，which may lead to unsafe evaluation re⁃
sults.
Keywords： tension-compression conversion; dam concrete; dynamic damage; stiffness recovery; dynamic cy⁃
clic loading; constitutive model
（责任编辑：王冰伟）
